The prototype of "Kapok Boys" in Guangzhou Baiyun Station appears!Steel structure "pe

Author:Guangzhou, China Time:2022.06.14

A beautiful "Kapok"

It is about to bloom on the Guangzhou Baiyun Station project

Bleak

Guangzhou Baiyun Station

The appearance of the "Kapok" appears

recently

Guangdong -Hong Kong -Macao Greater Bay Area

Key traffic infrastructure project

Guangzhou Baiyun Station is completed

About 4,000 tons of steel structure petals assembly engineering node

The appearance of "Yunshanzhu Water, Kobeo"

Officially appeared!

▲ Guangzhou Baiyun Station construction site

Construction overview

Guangzhou Baiyun Station Station Building Building

The concept of "Yunshanzhu Water and Kapok" as the concept of construction

▲ Guangzhou Baiyun Station renderings

The first phase of the station building petals belong to the structure of the grid -based diameter diameter column structure.

● 15 meters high in the ribbon petals, and the maximum suspended 10 meters;

● The inner petals are 15 meters high and the maximum canther 15 meters;

● The outer petals are 19 meters high, and the maximum suspension is 28 meters.

▲ Guangzhou Baiyun Station construction site

Large volume, many nodes, and cantilents are the main features of the steel structure petals of Guangzhou Baiyun Station.

This time, the internal and external petal assembly uses hanging installation technology. Relying on BIM technology, the visual three -dimensional model of the Guangzhou Baiyun Station project is constructed. The builder has achieved visual construction, effectively solving the problem of pipeline conflicts and complicated steel structure nodes.

Guangzhou Baiyun Station

Is one of the largest railway station comprehensive hub in Asia

After the project is completed

Will undertake Guangzhou Station and Guangzhou East Station

All general bus

In addition to unique features

Construction of Guangzhou Baiyun Station

Also highlights

Bleak

"Super Station"

Covering the area is equivalent to 4 Guangzhou South Station

Guangzhou South Station, the number one in the country

Covering an area of ​​615,000 square meters

The total area of ​​Baiyun Station reached 2.63 million square meters

It is 4 times that of Guangzhou South Railway Station

▲ Guangzhou Baiyun Station renderings

Guangzhou Baiyun Station General

According to the concept of "Greater Bay Area on the Rail"

Build

World -Class Modern Comprehensive Transportation Hub Fate Large Railway Station

Plaza can breathe

In order to solve the specific node

Practice of flow of people

Guangzhou Baiyun Station Innovation proposed

Smart concept of "retractable station, breathing square"

Create the two breathing squares of the east and west

▲ Guangzhou Baiyun Station renderings

● Usually, the square not only gathers the function of landscape and leisure, but also can become a space for display and performance, so that passengers can also feel the cultural atmosphere of Guangzhou when waiting for the car.

● During the Spring Festival, the breathing square can be expanded into a "elevated waiting room" to accommodate three times more passengers.

Six subway lines

In the future Guangzhou Baiyun Station will have up to 6 subway lines.

Including the north extension section of the Guangzhou Metro Line 8 and the 12th Line 12, the intercity, Line 24 and Foshan Metro Line 8, which have been under construction, and a new line of east to west.

▲ Guangzhou Baiyun Station will have multiple subway lines to meet

Baiyun Station will be supported

Long -distance passenger transport center, tourist bus station field

He and urban bus station and so on

Large -scale comprehensive transportation hub

In addition, Baiyun Station will use TOD mode

Comprehensive development

(That is, a comprehensive development model guided by public transportation)

Including hotels, apartments, office,

Mall and other composite functions

According to the plan

Guangzhou Baiyun Station

It is expected to be completed and operated by the end of 2023

At that time, the project will be the national railway development

Construction of the "Greater Bay Area on the Rail"

Inject new effective motivation

Edit 丨 Zhong Xintong

Responsible editor | 禤 Zhijie

School Division | Zeng Weilei

Source 丨 Guangzhou Baiyun Published

- END -
