Wuhan has added a new river bridge, and the design details are here

On June 29, the official website of the Wuhan Public Resources Exchange Center issued the "Jianghan Ten Bridge and Cross -Strait Wiring Engineering Supervision" bidding results.

According to the announcement issued by the Wuhan Public Resources Trading Center, the project starts from Zhu Road, Golden Estate Avenue, and east of Changyun intersection of Gutian Road. ), 188 meters, the main line of the ground is 1618 meters, the ground auxiliary road is 1829 meters, and the road red line is 40-55 meters wide.

Jianghan Ten Bridge renderings (specifically based on actual construction). Picture source: Hanyang District Rong Media Center

Specific situation ↓↓↓

Positive bridge: 380 -meter -off -supported simplified steel box raised basket arch bridge. The cross -strait bridge is 475 meters, the bridge deck is 41.5 meters wide, and 6 lanes in both directions.

Hanyang Bank Wiring: Rebuilding the status quo after the current status of Budweiser is 280 meters. The main line includes the wiring viaduct about 1270 meters, the main line of the ground is 155 meters, and the two -way 6 lanes; The length of the ramp is about 550 meters, 8 meters wide, and one -way dual lanes. The upper and lower bridge ramps are located on both sides of the third ring line of Baili Road.

Han Port Wiring: The main line includes the wiring viaduct 190 meters, two -way 6 lanes, the main line of the ground is 1463 meters long, and the two -way 6-8 lanes; The main construction contents include roads, bridges, drainage, transportation, greening, lighting, and related supporting projects. The new power tunnel is built between Gutian Road and Changyun Road.

Scope of bidding: Jianghan Ten Bridge and Cross -Strait Wiring Project Construction Supervision.

Construction scale: The main bridge is proposed to adopt a bridge plan, set up a two -way 6 -lane, and adopts the "White Summary Steel Tank Basic Basketball" bridge structure solution. No less than 8 lanes) to connect the elevated project of the northern section of Gutian Road, and the main bridge of Hanyang District connects the Baili Road elevated. Among them, the Parkway Road elevated from the current status of 4 lanes to 6 lanes.

The project of the project is the Wuhan Hongcheng Engineering Consultation Management Co., Ltd.. The project's planned supervision and related service period: 1185 calendar days (the planned construction period is 1095 days, and the supervision service period is based on the planned construction period. To.

According to the previous report from the Rong Media Center of Hanyang District, Jianghan Tenth Bridge is located between the Changfeng Bridge and the Gutian Bridge. It is connected to Gutian, Hankou to the north. Sichuan Avenue, with a total length of 4.3 kilometers.

The bridge has two -way 6 lanes, 2.5 kilometers from the upstream Changfeng Bridge, 1.5 kilometers downstream of Gutian Bridge. After completion, it will not only greatly optimize the transportation environment of Huiminyuan area, but also support large -scale urban renewal and functional transformation in Hanyang Golden mouth, four, rice grain and other areas.
